9/16″ Dia. × 0.630″ Shank × 13.858″ Flute Length × 15.906″ OAL, 20xD, 140 Degrees, Axial Inclined Exit, DIN 6535 HA, Cylindrical Solid Carbide Drill DC160 WJ30EU
Item #: TT107684331
Brand: Walter-Titex
Model #: 7684331
| Product Specifications | |
|---|---|
| Drill Bit Size / Cutting Diameter (DC) | 9/16″ |
| Shank Standard | DIN 6535 HA |
| Decimal Equivalent | 0.5625″ |
| Cutting Edge Material | Carbide |
| Length Group | 20xD |
| Tool Type | High Performance |
| Coating | TiSiAlCrN / TiAlN |
| Grade | WJ30EU |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials |
| Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 0.63″ |
| Series/List # | DC160 |
| Coolant Supply Property (CSP) | Coolant Thru |
| Usable Length (LU) | 13.228″ |
| Point Angle (SIG) | 140 Degrees |
| Length Chip Flute (LCF) | 13.858″ |
| Functional Length (LF) | 13.858″ |
| Overall Length (OAL) | 15.906″ |
| Flute Helix Angle (FHA) | 30 Degrees |
| Flute Count (NOF) | 2 |
| Shank Length (LS) | 1.89″ |
| Cutting Direction (HAND) | Right Hand |
| Shank Type | Cylindrical |
| Body Material | Carbide |
