Electro Hardware - M3 Screw 3mm OAL 3.2 to 3.6mm ID x 4.5mm OD Round Aluminum Circuit Board Spacers - Exact Tooling

Electro Hardware - M3 Screw 3mm OAL 3.2 to 3.6mm ID x 4.5mm OD Round Aluminum Circuit Board Spacers


Item #: 77126324
Brand: Electro Hardware
Model #: MS405M04F16D

Features and Benefits

Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
Product Specifications
Type Female Unthreaded
Material Aluminum
System of Measurement Metric
Body Shape Round
Screw Size M3
Outside Diameter (mm) 4.5
Overall Length (mm) 3.0
Inside Diameter (mm) 3.2 to 3.6
Finish/Coating Uncoated
Material Grade T-3
Inside Diameter Tolerance (mm) 0.000 to 0.270
Length Tolerance (mm) -0.130 to 0.130
Fastener Standard QQ-A-225A Comp 2
