CCPM61525R CARBIDE SHANK PROFILING
Item #: WK212831020
Brand: Widia
Model #: 2831020
| Product Specifications | |
|---|---|
| Connection Diameter Machine Side (DCONMS) | 6 mm |
| Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 152.4 mm |
| Coolant Supply Property (CSP) | Coolant Thru |
| Reduced Body Diameter Length (LDRED) | 12.79 mm |
| Shank Type | Round |
| Head Length (LH) | 2.5 mm |
| Rake Angle Axial (GAMP) | 0 Degrees |
| Master Insert Identification (MIID) | Rhombic 45 |
| Rake Angle Radial (GAMF) | 0 Degrees |
| Minimum Bore Diameter (DMIN) | 9.14 mm |
| Body Material | Carbide |
