CSBM6412325R STEEL SHANK STEP
Item #: WK212831468
Brand: Widia
Model #: 2831468
| Product Specifications | |
|---|---|
| Shank Height (H) | 12 mm |
| Cutting Direction (HAND) | Right Hand |
| Shank Width (B) | 12 mm |
| Master Insert Identification (MIID) | Diamond 80 |
| Protruding Length (LPR) | 31.75 mm |
| Coolant Supply Property (CSP) | Coolant Thru |
| Overall Length (OAL) | 70 mm |
| Shank Type | Round |
| Head Length (LH) | 31.75 mm |
| Rake Angle Axial (GAMP) | 5 Degrees |
| Connection Diameter Machine Side (DCONMS) | 12 mm |
| Rake Angle Radial (GAMF) | 0 Degrees |
| Minimum Bore Diameter (DMIN) | 7.24 mm |
| Body Material | Steel |
