CCPI25065L CARBIDE SHANK PROFILING
Item #: WK212831767
Brand: Widia
Model #: 2831767
| Product Specifications | |
|---|---|
| Connection Diameter Machine Side (DCONMS) | 1/4″ |
| Cutting Direction (HAND) | Left Hand |
| Overall Length (OAL) | 6″ |
| Coolant Supply Property (CSP) | Coolant Thru |
| Reduced Body Diameter Length (LDRED) | 0.484″ |
| Shank Type | Round |
| Head Length (LH) | 0.09″ |
| Rake Angle Axial (GAMP) | 0 Degrees |
| Master Insert Identification (MIID) | Rhombic 45 |
| Rake Angle Radial (GAMF) | 0 Degrees |
| Minimum Bore Diameter (DMIN) | 0.36″ |
| Body Material | Carbide |
