CSPI25050010R STEEL SHANK PROFILING
Item #: WK212832297
Brand: Widia
Model #: 2832297
| Product Specifications | |
|---|---|
| Connection Diameter Machine Side (DCONMS) | 1/2″ |
| Body Material | Steel |
| Head Length (LH) | 1″ |
| Usable Length (LU) | 4″ |
| Overall Length (OAL) | 4″ |
| Cutting Depth Maximum (CDX) | 0.09″ |
| Coolant Supply Property (CSP) | Coolant Thru |
| Measurement Type | Inch |
| Cutting Direction (HAND) | Right Hand |
| Body Diameter Reduced (BDRED) | 0.26″ |
| Functional Width (WF) | 0.22″ |
