Brand: Widia / Part #: 3852753
Item #: 97325997
Brand: Widia
Model #: 3852753
Product Specifications
| Cutting Direction | Neutral |
| Hand of Holder | Neutral |
| Compatible Insert Size Code | TN..220408 |
| Toolholder Style | MTENNS |
| Rake | Negative |
| Rake Angle | -10 |
| Multi-use Tool | No |
| Lead Angle | 60.000 |
| Insert Holding Method | Clamp |
| Shank Width (mm) | 25.00 |
| Shank Height (mm) | 32.00 |
| Series | MTEN |
| Overall Length (mm) | 170.0000 |
| Cutting Tool Application | Turning |
| Head Length (mm) | 35.00 |
| Back of Bar to Cutting Edge (mm) | 12.25 |
| Primary Workpiece Material | Universal |
| Center to Cutting Edge (Decimal Inch) | 0.4823 |
| Insert Width (mm) | 22.00 |
| Toolholder Material | Steel |
| ISO Number | MTENNS3225P22 |
| Complete Insert Compatibility | TN..43. |
| Insert Thickness | 4.76 |
| Coolant Through | No |
| Insert Inscribed Circle (mm) | 12.70 |
